I don't have a schematic or scope handy to check this for sure, but it may also be that the coupling cap to the Reset line from the CH part to the Mega2560 Reset is too small. The symptoms and his fix seem to say the hardware Reset pulse is too short in some cases, but there is enough of a timing window (in software) for the IDE to accept a manual reset if you get it at just the right time.
ARDUINO MEGA 2560 USB DRIVER DOWNLOAD SERIAL
Since it worked forme, this would seem to indicate a timing problem with the Reset pulse being too short (not getting recognized) on some systems using the CH340/341 USB to serial chips. If you want to be able to upload a compiled Arduino sketch (HEX file) to your Arduino board without using the Arduino IDE there has been no easy way without knowing the ins and outs of AVRDude or other command line programmers. Uploading Arduino HEX files with XLoader. Another hint was to set the Preferences for Verbose (both compiler and bootloader), which consumes a bit more time with extra messages. Uploading Arduino HEX files with XLoader. It has 54 digital input/output pins (of which 14 can be used as PWM outputs), 16 analog inputs, 4 UARTs (hardware serial ports), a 16 MHz crystal oscillator, a USB connection, a power jack, an ICSP header, and a reset button.
This guys says to manually hit the Mega reset pushbutton just as the green progress bar on the IDE from the compilation hits the right end. The Arduino Mega 2560 is a microcontroller board based on the ATmega2560 (datasheet). When there is a problem with the reset (the reset is needed to connect to the bootloader to upload a sketch), then get rid of that board. When you use the Arduino IDE to burn the bootloader, then also the fuses will be set to their proper values. Use a programmer and the Arduino IDE to burn the newest bootloader into the Arduino Mega 2560.
ARDUINO MEGA 2560 USB DRIVER DOWNLOAD DRIVERS
When using a cheap clone board with the CH340G, use the drivers of the official website:
ARDUINO MEGA 2560 USB DRIVER DOWNLOAD INSTALL
Install the newest Arduino IDE from the official website: This is important, don't think you can skip this step.Īfter that you can start with a fresh new install. The Arduino MEGA is a microcontroller board based on the ATmega2560. The MEGA is a robust, well documented board with a large and helpful user community - making it easy to start tinkering. The MEGA is one of best boards to get started with electronics and coding.
The Arduino has its own mini version of Java, and an other Java could get in the way.įind the hidden "arduino15" folder(s). This Arduino MEGA 2560 R3 board comes with a genuine ATmega16U2 USB/UART chip. Remove all the usb-serial drivers that you have installed. Delete the C:\Program Files (x86)\Arduino folder, because there could still be files that mess up the new version. The trouble with the '!!!' is fixed, and also a number of other bugs have been fixed in the bootloader for the Arduino Mega 2560. The best thing to do is to burn a new bootloader into the Arduino Mega 2560 board, together with the newest Arduino IDE, and remove all old things that are on your computer.ĭo you have a programmer ? You should get one.
